Sinotruk Sitrak T7H 8X4 40 Ton Dump Truck
Sinotruk Sitrak T7H 8X4 40 Ton Dump Truck
SPECIFICATIONS
After-sales Service Provided: Video Technical Support
Brand Name: Top Brand
Capacity (Load): 31 - 40T
Cargo Tank Dimension: custom
Cargo Tank length: 6.2-8m
Condition: New
Dimensions (L x W x H) (mm): 8750*2550*3450mm
Drive Wheel: 6X4
Emission Standard: Euro 2
Engine Capacity: > 8L
Forward Shift Number: custom
Fuel Type: Diesel
Gross Vehicle Weight: 20-25T,14000-100000 kg
Horsepower: 351 - 450hp
Market Segement: Mining transportation
Maximum Torque(Nm): 2000-2500Nm
Passengers: 6
Place of Origin: China
Rear Camera: 360°
Segement: Medium-sized truck
Steering: Left
Touch Screen: Yes
Feature For Howo 336Hp/371Hp 6*4 Dump Truck
Our Main Products Heavy Trucks and Construction Machinery. include Howo tractor trucks, dump trucks, trailer truck,Fire trucks, water tank trucks, concrete mixer trucks, special trucks,truck parts and Motor grader,wheel loader, roller loader.
We can supply these for our clients with good quality and competitive price.
Parameter For Howo 336Hp/371Hp 6*4 Dump Truck
| MAIN DESCRIPTION | ||||
| Overall Dimension | 8545mm*2496mm*3350mm (L*W*H) | |||
| Payload | 25-30ton | Curb Weight | 12500kg | |
| Front Overhang | 1500mm | Rear Overhang | 1870mm | |
| Wheelbase | 3825mm +1350mm | |||
| CHASSIS | ||||
| Chassis Brand | SINOTRUK HOWO | |||
| Driving Type | 6x4 | |||
| Cab | HW76, left hand drive, air-conditioner, one bed | |||
| Engine and Power |
Brand: SINOTRUK, diesel engine, 336hp (247kw), 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, Euro II emission standard |
|||
| Steering | hydraulic steering with power assistance | |||
| Transmission | HW15710, 10 forward speeds and 2 reverse | |||
| Clutch | Model: 430, diaphragm clutch | |||
| Front Axle | HF9, load capacity 9 ton, drum brake | |||
| Rear Axle | HC16 tandem axle, load capacity 13000kg x2, ratio 5.73 | |||
| Tire | 12.00-20, 11units including 1 spare tire | |||
| CARGO BODY | ||||
| Inside Dimension | 5600mm*2300mm*1500mm(L*W*H) | |||
| Hydraulic Cylinder | Ventral T-type lift system | |||
| Steel sheet thickness | Floor 8mm, side wall 6mm | |||
| Tailgate | One-piece tailgate with upper articulation, safety lock system | |||
